Laser Tree K1 Mini 10W Laser Cutting & Engraving CNC Machine

Can you start the first step in your dream business with a little money? Laser Tree K1 Mini is an affordable LASER engraving and cut machine offers you a complete solution.

The laser engraving machine uses a 10W (true / effective power) laser module to cut 8mm plywood in a single pass, with a laser spot as small as 0.08 mm for finer engraving. The work plate works in conjunction with an air pump to remove debris and remove smoke, avoiding yellowing of the wood and allowing you to realize most of your creations.

Featrures

• Cut Acrylic and Plywood (8 mm).
• Maximum engraving Speed: 6000 mm/min.
• Working Area: 300 x 300 mm.
• Excellent entry level for Laser cutting profession.

Specifications

Optical power (Effective Power)	10 W (± 1 W)
Input voltage and current	12 VDC 5 A
Wave lenght	450 nm (± 10 nm)
Spot size of the laser beam	0.08*0.08 mm
Focal Length	45mm
Engrave Area	300x300 mm
Weight	3.5 kg



Package Includes:

Laser Tree K1 Mini 10W Laser Cutting & Engraving Machine user manual
