Straw Hat LED Diode is a high-brightness light-

Product image 1

Straw Hat LED Diode is a high-brightness light-

Product Description

The 4.8mm Straw Hat LED Diode is a high-brightness light-emitting diode designed with a flat top (straw hat shape) that provides a wide viewing angle compared to standard round LEDs. This design distributes light more evenly, making it ideal for lighting panels, decorative lighting, indicators, and electronic projects.

The LED features a transparent epoxy lens and through-hole leads, making it easy to use in breadboards, PCB circuits, Arduino projects, and DIY electronics.

Key Features

  • Straw hat  lens for wide light distribution

  • 4.8mm LED package

  • Wide viewing angle

  • Low power consumption

  • Long operating life

  • Easy through-hole mounting

  • Suitable for Arduino, Raspberry Pi, and electronics projects

Technical Specifications

Parameter                                              Specification
LED Type Straw Hat LED
Diameter 4.8 mm
Package Type Through-Hole
Lens Type Transparent Flat Top
Viewing Angle 120° – 160°
Forward Voltage 2.0 – 3.3 V (depends on color)
Forward Current 20 mA
Max Current 30 mA
Lead Pitch 2.54 mm
Lifespan Up to 50,000 hours



Pin Configuration

Pin                                                  Description
Anode (+) Longer lead
Cathode (-) Shorter lead



Applications

  • LED lighting modules

  • Decorative lighting

  • Electronic indicators

  • DIY electronics projects

  • Arduino and microcontroller circuits

  • LED displays and panels

Package Includes

1 × 4.8mm Straw Hat LED Diode

$0.01

Original: $0.02

-50%
