Uno R3 - Clone Original Chips original FTDI ATML MEGA16U2

The UNO R3 is backwards compatible with the Arduino UNO - same driver, same uploading, same look.

Uno R3 - Clone original FTDI ATML MEGA16U2

Description

• There are a few changes in the UNO, here is what they are
• ATmega16U2 instead of the 8U2 found. This allows for faster USB transfer rates.
• No drivers needed for Linux or Mac (.inf file for Windows is needed and included in the Arduino IDE)
• The ability to have the Uno show up as a keyboard, mouse, joystick, etc.
• New SDA and SCL pins next to the AREF. this is a duplication of the Analog 4 and 5 pins.
• Two new pins placed near the RESET pin. One is the IOREF that allow the shields to adapt to the voltage provided from the board. The other is a not connected and is reserved for future purposes.
• Reset button moved from center of board to corner near USB connector, allowing resets when shields are connected.
• Larger heat sink copper area for the LM117 regulator
